Technical Data
Order No.
9012405
Model series
CORIO
Category
Heating Bath Circulators with Open Bath
Working temperature range (°C)
+20 ... +150
Temperature stability (°C)
± 0.03
Setting / display resolution
0.1 °C
Temperature Display
LED
Heating capacity (kW)
2
Pump capacity flow rate (l/min)
15
Pump capacity flow pressure (bar)
0.35
Bath opening / bath depth (W x L / D cm)
15 x 15 / 15
Pump connections
M16x1
Filling volume (liters)
3.5 ... 5
Ambient temperature
5...40 °C
Dimensions W x L x H (cm)
23 x 38 x 41
Weight (kg)
8.2
Included with each unit
2 barbed fittings suitable for tubing 8 and 12 mm inner dia. (pump connections M16x1 male)
Cooling coil
Optional
Bath tank
Stainless steel
Bath cover
Optional
